The EC510 is a conductivity test kit. The kit includes the EC500 meter, three calibration standards, three pH buffer pouches with rinse solution, three cups, batteries, and a carrying bag. Uses a single electrode to measure five parameters: conductivity, TDS, salinity, pH, and temperature. Analog bar graphs show trends. Memory can store up to 25 labeled readings. The conductivity-to-TDS ratio can be adjusted from 0.4 to 1.0, whereas the salinity ratio is fixed at 0.5.
| Conductivity | 0 to 199µS/cm, 200 to 1999µS/cm, 2.00 to 19.99mS/cm |
|---|---|
| Conductivity Basic Accuracy | ±2% full scale |
| Conductivity Max Resolution | 0.1µS/cm |
| Memory | 25 datasets |
| pH | 0.00 to 14.00pH |
| pH Basic Accuracy | ±0.01pH |
| pH Max Resolution | 0.01pH |
| TDS | 0 to 99.9ppm (mg/L), 100 to 999ppm (mg/L), 1.00 to 9.99ppt |
| TDS Basic Accuracy | ±2% full scale |
| TDS Max Resolution | 0.1ppm (mg/L) |
| Temperature (Contact) | 23° to 194°F (-5 to 90°C) |
| Temperature (Contact) Basic Accuracy | ±1.8°F/1°C |
| Temperature (Contact) Max Resolution | 0.1°F/°C |
| Certifications | CE |
| Dimensions | 1.4 × 6.8 × 1.6" (35.6 × 172.7 × 40.6mm) |
| IP Rating | IP57 |
| Power | 4 × CR-2032 (3V) batteries |
| Warranty | 2 years |
| Weight | 3.8oz (110g) |
