HB-CCD-B

Details: Category: Brinell / Rockwell / Vickers / Hardness Tester

This system include the electronic or digital Brinell hardness tester and Brinell measurement software, hardness indentation could be fast read to the computer by portable microscope; only needed to use keyboards and mouse, after the software automatically calculates that can complete the test require- ments, can improves working efficiency, it is a perfect solution to test hardness value.

Main function and features:

Standard configuration: BRINELL hardness measurement software, dongle, HD CCD, USB data trans mission line, computer equipment (optinal)

Image analysis software can be customized for kinds of functions, completed, handy operation and meet most customers’ demands

It can enlarge the indentation image measurement, and can be amplified again for diagonal part to avoid manual error.

It can automatic to identify the indentation image and measure the indentation diameter for bright and clear sample surface

Real time display the indentation diameter, hardness value, indentation depth, material strength, conversion hardness value and etc.

It possesses the unique mark positioning function, testing the positioned point hardness value..

It can be adjusted the color, gray, contrast ratio, lightness of the image.

Attached with function of indentation tangency fine tuning, length measurement and angle measurement etc.

It possesses the function of test result statistical analysis, automatic generation and export for the format of Word, and Excel of hardness measurement analysis report, and save the indentation image, print etc.

Support WINXP,WIN7,WIN10, 32 & 64 bit operation system.

Model	BHT-3000E	BHT-3000D
Brinell scale	HBW2.5/62.5, HBW2.5/187.5, HBW5/125, HBW5/750, HBW10/100, HBW10/250, HBW10/500, HBW10/1000, HBW10/1500, HBW10/3000
Test force	62.5kgf(612.9N), 100kgf(980.7N), 125kgf(1226N), 187.5kgf(1839N), 250kgf(2452N), 500kgf(4003N), 750kgf(7355N), 1000kgf(8907N), 1500kgf(1471N), 3000kgf(29420N)
LCD Screen size	none	118x99mm
Minimum measuring unit	0.005mm	0.00125mm
Measuring range	8–650HBW
Hardness value read	Check table	Digital LCD
Hardness range	8-650HBW
Total amplification	20X
Load method	Automatic(load, dwell, unload)
Dwell time	1-99s (each step 1s)
Max height allowed	220mm
Throat depth	120mm
Instrument size and weight	530x187x758mm (LxWxH) 135kg
Package size and weight	625x430x950mm (LxWxH) 149kg
Power supply	AC220V + 5%, 50–60 Hz AC110V available
Executive standard	ASTM E10, ISO 6506, JJG150, GB/T231.2 inspection rules
Standard accessories	Hardness tester; 20X measuring objective; 82.5, 85, 810mm harden alloy indenter; big, medium and "V" test table; power cable; accessory box; dust-proof cover; manual instruction; 2 pieces Standard hardness block
Optional accessories	Hardness measurement software (HB-CCD-B); computer; printer; standard indenter; standard block.
