Measuring range

External direct measuring range: 0-100mm

External comparison measuring range: 0-700mm

Internal direct measuring range: 2-100mm

Internal comparison measuring range: 10-450mm

External thread measuring range: till 200mm

Internal thread measuring range: M13 - M90

Work table

Vertical distance: 0-100mm/1mm

Horizontal distance: 0-25mm/ 0.01mm

Left-right swivel angle: ±4°

Up-down tilt angle: ±3°

Resolution：	0.0001mm/0.000001”
Measuring accuracy：	±(0.5+L/200)um
Uncertainty of measurement：	(0.2+L/200)um
Measuring force：	0、1.5、2.5N
The best temperature of measurement：	20°C ± 1°C
Power：	220V±10%
Instrument weight：	100KG
Instrument dimension：	1000x380x450mm
