For measuring width, inside diameter, inside groove diameter.
| Model No. | Measuring Range | Accuracy | Dimension (mm) |
|---|---|---|---|
| IC-9015 | 15-35mm | 30um | A: 3 B: Φ3 L: 50 |
| IC-9035 | 35-55mm | A: 6 B: Φ3 L: 80 | |
| IC-9055 | 55-75mm | A: 8 B: Φ3 L: 90 | |
| IC-9075 | 75-95mm | A: 8 B: Φ3 L: 100 | |
| IC-9095 | 95-115mm | A: 10 B: Φ3.2 L: 150 | |
| IC-9115 | 115-135mm | A: 10 B: Φ3.2 L: 150 |
Graduation：0.01mm
