| Model No. | Calibration Range | Combination Max.error | Remark |
|---|---|---|---|
| LEN-9001 | 200mm | 0.002mm | Accuracy :±0.0015mm (all parts) |
| LEN-9002 | 300mm | 0.003mm | |
| LEN-9003 | 600mm | 0.005mm | |
| LEN-9004 | 1000mm | 0.008mm |
*Must be paired with flawless gauge blocks, and placed in the best temperature control environment within ≦ ±1°C
*Inspection reading: 0.1um
