Airflow Meters

Details: Category: Airflow Meters

Extech AN300-C Airflow Cone and Funnel Adapter Kit for AN300, AN310, AN320 — Airflow Cone and Funnel Adapter Kit for AN300, AN310, AN320

The Extech AN300-C is an airflow cone and funnel adapter kit. For use with the AN300, AN310, and AN320 meters. The accessory kit enables rapid and easy airflow measurements in common large-size ducts.

Details: Category: Airflow Meters

Extech SDL350 Hot Wire CFM Thermo-Anemometer/Datalogger — Hot Wire CFM Thermo-Anemometer/Datalogger

The SDL350 saves data to an SD card in Excel format. Air Velocity/Flow meter with telescopic probe that fits into HVAC ducts and other narrow apertures. The telescoping probe has a maximum length of 7.05ft (215cm) with cable. The data sample rate is adjustable. Stores 99 manual readings and 20M readings on a 2GB SD card. Type K/J thermocouple input for high-temperature measurements. The large (9999 count) LCD displays both air velocity or flow and temperature at the same time. Record and recall MIN, MAX, Data Hold, and Auto Power Off. Comes with 6 AA batteries, an SD card, a telescopic probe with cable, and a protective carrying bag.

Specifications

Air Velocity (ft/min)	40 to 3940ft/min
Air Velocity (ft/min) Basic Accuracy	±5% of reading
Air Velocity (ft/min) Max Resolution	1ft/min
Air Velocity (km/h)	0.7 to 72km/h
Air Velocity (km/h) Basic Accuracy	±5% of reading
Air Velocity (km/h) Max Resolution	0.01km/h
Air Velocity (knots)	1 to 31knots
Air Velocity (knots) Basic Accuracy	±5% of reading
Air Velocity (knots) Max Resolution	0.01knots
Air Velocity (m/s)	0.2 to 25m/s
Air Velocity (m/s) Basic Accuracy	±5% of reading
Air Velocity (m/s) Max Resolution	0.01m/s
Air Velocity (mph)	0.5 to 45MPH
Air Velocity (mph) Basic Accuracy	±5% of reading
Air Velocity (mph) Max Resolution	0.01MPH
Air Volume (CFM)	0 to 1,907,000 CFM
Air Volume (CFM) Max Resolution	0.001 to 1 CMM
Air Volume (CMM)	0 to 54,000 CMM
Memory	20 Million data records using 2G SD card
Temperature (Air)	32 to 122 °F (0 to 50 °C)
Temperature (Air) Basic Accuracy	±1.5°F ( ±0.8°C)
Temperature (Air) Max Resolution	0.1°
Temperature (Type J) Basic Accuracy	-148 to 2192 °F (-100 to 1200 °C)
Temperature (Type J) Max Resolution	±(0.4% + 1.8 °F/1 °C)
Temperature (Type K) Basic Accuracy	0.1°
Temperature (Type K) Max Resolution	-148 to 2372 °F (-100 to 1300 °C)
Temperature (Type N)	0.1°
Temperature (Type N) Basic Accuracy	±(0.4% + 1.8 °F/1 °C)
Certifications	CE
Dimensions	7.2 × 2.9 × 1.9" (182 × 73 × 47.5mm)
Power	6 × AA (1.5V) batteries
Warranty	3 years
Weight	23.1oz (655g)

Details: Category: Airflow Meters

Extech SDL310 Electronic Test Lead Kit — Electronic Test Lead Kit

The SDL310 saves data to an SD card in Excel format. Air temperature is measured to 122°F (50°C), and air velocity is 4930 feet per minute. Stores 99 manual readings and 20M readings on a 2GB SD card. Stores 99 manual readings and 20M readings on a 2GB SD card. Type K/J thermocouple input for high-temperature measurements. The large (9999 count) LCD displays both air velocity and temperature. On a 39-inch vane wheel, low friction ball bearings provide 2% velocity accuracy. (1 m) cable. Record/recall the minimum, maximum, data hold, and auto power off. The data sample rate is adjustable. Comes contains 6 AA batteries, an SD card, a vane sensor with a 3.9ft (120cm) wire, and a protective carrying bag.

Specifications

Air Velocity (ft/min)	80 to 4930ft/min
Air Velocity (ft/min) Basic Accuracy	±2% of reading
Air Velocity (ft/min) Max Resolution	1ft/min
Air Velocity (km/h)	1.4 to 90.0km/h
Air Velocity (km/h) Basic Accuracy	±2% of reading
Air Velocity (km/h) Max Resolution	0.1km/h
Air Velocity (knots)	0.8 to 48.6knots
Air Velocity (knots) Basic Accuracy	±2% of reading
Air Velocity (knots) Max Resolution	0.1knots
Air Velocity (m/s)	0.4 to 25m/s
Air Velocity (m/s) Basic Accuracy	±2% of reading
Air Velocity (m/s) Max Resolution	0.01m/s
Air Velocity (mph)	0.9 to 55.9MPH
Air Velocity (mph) Basic Accuracy	±2% of reading
Air Velocity (mph) Max Resolution	0.1MPH
Memory	20,000K data records using 2G SD card
Temperature (Air)	32 to 122 °F (0 to 50 °C)
Temperature (Air) Basic Accuracy	±1.5 °F (±0.8 °C)
Temperature (Air) Max Resolution	0.1°
Temperature (Type J) Basic Accuracy	-148 to 2192 °F (-100 to 1200 °C)
Temperature (Type J) Max Resolution	±(0.4% of reading + 1.8°F/1°C)
Temperature (Type K) Basic Accuracy	0.1°
Temperature (Type K) Max Resolution	-148 to 2372 °F (-100 to 1300 °C)
Temperature (Type N)	±(0.4% + 1.8°F/1°C)
Temperature (Type N) Basic Accuracy	0.1°
Certifications	CE
Dimensions	7.2 × 2.9 × 1.9" (182 × 73 × 47.5mm)
Power	6 × AA (1.5V) batteries
Warranty	3 years
Weight	16.9oz (480g)

Details: Category: Airflow Meters

Extech SDL300 Metal Vane Thermo-Anemometer/Datalogger — Metal Vane Thermo-Anemometer/Datalogger

The SDL300 saves data to an SD card in Excel format. The metal vane can endure temperatures up to 158°F (70°C) and air velocity up to 6900ft/min. Dataloggers date and time stamp readings and store them on an SD card in Excel format for easy transfer to a PC. The data sample rate can be set anywhere between 1 and 3600 seconds. Stores 99 manual readings and 20M readings on a 2GB SD card. Type K/J thermocouple input for high-temperature measurements. The large (9999 count) LCD displays both air velocity and temperature. 2% velocity accuracy with low friction ball bearing vane wheel on 39" (1m) wire. Record/Recall MIN, MAX, Data Hold, Auto Power Off. Complete with 6 x AA batteries, SD card, metal vane sensor with 3.9ft (120cm) cable, and sturdy carrying bag.

Specifications

Air Velocity (ft/min)	60 to 6900ft/min
Air Velocity (ft/min) Basic Accuracy	±2% of reading
Air Velocity (ft/min) Max Resolution	1ft/min
Air Velocity (km/h)	1.0 to 126.0km/h
Air Velocity (km/h) Basic Accuracy	±2% of reading
Air Velocity (km/h) Max Resolution	0.1km/h
Air Velocity (knots)	0.6 to 68knots
Air Velocity (knots) Basic Accuracy	±2% of reading
Air Velocity (knots) Max Resolution	0.1knots
Air Velocity (m/s)	0.4 to 35m/s
Air Velocity (m/s) Basic Accuracy	±2% of reading
Air Velocity (m/s) Max Resolution	0.1m/s
Air Velocity (mph)	0.7 to 78.2MPH
Air Velocity (mph) Basic Accuracy	±2% of reading
Air Velocity (mph) Max Resolution	0.1MPH
Memory	20M data records using 2G SD card
Temperature (Air)	32 to 158 °F (0 to 70 °C)
Temperature (Air) Basic Accuracy	±1.5°F/0.8°C (<60°C)
Temperature (Air) Max Resolution	0.1 °
Temperature (Type J) Basic Accuracy	-148 to 2192 °F (-100 to 1200 °C)
Temperature (Type J) Max Resolution	±(0.4% + 1.8°F/1°C)
Temperature (Type K) Basic Accuracy	0.1°
Temperature (Type K) Max Resolution	-148 to 2372 °F (-100 to 1300 °C)
Temperature (Type N)	±(0.4% of reading + 1.8°F/1°C)
Temperature (Type N) Basic Accuracy	0.1°
Certifications	CE
Dimensions	7.2 × 2.9 × 1.9" (182 × 73 × 47.5mm)
Power	6 × AA (1.5V) batteries
Warranty	3 years
Weight	17.2oz (487g)
